S Series
Squirrel cage three-phase asynchronous motors for high temperatures
Power 0,09÷500 kW
Frame sizes 63÷355
Insulation Class H
Efficiency classes IE1/IE2/IE3
2, 4, 6, 8 poles motors and multi speed motors
Suitable for inverter supply
IEC 60034-1, IEC 60034-30
Standards (on request)
Protection degree – cooling
• IP 55 – IC 411 self-ventilated
• IP 55 – IC 418 external ventilation
Special construction for high temperature operation:
Classes:
– F200 (200°C for 120’)
– F300 (300°C for 60/120’)
– F400 (400°C for 120’)
Markets
Smoke extraction systems market
